Топливная система LH1000i
|
Наименование
|
Артикул
|
|
|---|---|---|
| 1. | fuel intake pipe,carburetor | LH1000i-370001 |
| 2. | negative press pipe | LH1000i-370002 |
| 3. | fuel intake pipe assy,negative press pump | LH1000i-371000 |
| 4. | clip Q671B8.5 | QCT621-1999Q671B8.5 |
| 5. | clip Q671B10 | QCT621-1999Q671B10 |
| 6. | negative press pump assy | LH1000i-372000 |
| 7. | cross recessed pan head tapping screw and plain washer st5x15 | GB9074.19-88Fst5x15 |
| 8. | gasoline switch assy | LH1000i-373000 |
| 9. | tapping screw st4.2×13 | GBT845-F-Hst4.2×13 |
| 10. | main switch knob | LH1000i-370003 |
| 11. | cross recessed small pan head screw and plain washer set M4x12 | GB9074.5-88M4x12 |
| 12. | flow pipe, fuel tank | LH1000i-370005 |
| 13. | stop cover | LH1000i-370008 |
| 14. | fuel tank | LH1000i-374001 |
| 15. | oil filling strainer assy. | LH1000i-374100 |
| 16. | oil outlet strainer assy | LH1000i-374200 |
| 17. | fuel tank cap assy | LH1000i-374300 |
| 18. | shock absorbing block ,fuel tank | LH1000i-374002 |
| 19. | gasket, fuel tank port | LH1000i-370006 |
| 20. | hose clamp | LH1000i-370007 |
| 21. | cross recessed pan head tapping screw and plain washer set st4.2×12 | GB9074.18-88Fst4.2×12 |
| 22. | clip Q673B9 | QCT621-1999Q673B9 |
