Внешний кожух в сборе LH2500i
|
Наименование
|
Артикул
|
|
|---|---|---|
| 1. | SCREW M5X12 | GBT9074.1-1988M5x12 |
| 2. | AIR INTAKE COVER | LH2000i-385100 |
| 3. | RIGHT OUTER COVER RED | LH2000i-383100A-R |
| 3. | RIGHT OUTER COVER BLUE | LH2000i-383100A-BL |
| 3. | RIGHT OUTER COVER ORANGE | LH2000i-383100A-Y |
| 4. | HEXAGON NUT M3 | GBT6170-2000M3 |
| 5. | CLIP NUT M5 | LH1000i-381004 |
| 6. | CHOKE CABLE | LH2000i-383003 |
| 7. | MOUNTING ABSORB CUSION 3, FUEL TANK | LH2000i-381002 |
| 8. | CYLINDER HEAD COVER CUSION | LH2000i-381003 |
| 9. | SPARK PLUG COVER RED | LH2000i-382001A-R |
| 9. | SPARK PLUG COVER BLUE | LH2000i-382001A-BL |
| 9. | SPARK PLUG COVER ORANGE | LH2000i-382001A-Y |
| 10. | SEAL RING | LH1000i-385003 |
| 11. | MUFFLER OUTER COVER | LH2000i-386100 |
| 12. | SCREW M5X15 | GB/T9074.1-1988 M5x15 |
| 13. | LEFT OUTER COVER RED | LH2000i-381100A-R |
| 13. | LEFT OUTER COVER BLUE | LH2000i-381100A-BL |
| 13. | LEFT OUTER COVER ORANGE | LH2000i-381100A-Y |
| 14. | OIL FILLING COVER RED | LH2000i-384001A-R |
| 14. | VOIL FILLING COVER BLUE | LH2000i-384001A-BL |
| 14. | OIL FILLING COVER ORANGE | LH2000i-384001A-Y |
| 15. | BOLT M6X13 | LH1000i-384002 |
| 16. | DRAINING FUEL COVER, CARBURETOR RED | LH2000i-380001A-R |
| 16. | DRAINING FUEL COVER, CARBURETOR BULE | LH2000i-380001A-BL |
| 16. | DRAINING FUEL COVER, CARBURETOR ORANGE | LH2000i-380001A-Y |
| 17. | SOUND-ABSORBING SPONGE (RIGHT) | LH2000i-383002 |
| 18. | SOUND-ABSORBING SPONGE (LEFT) | LH2000i-381001 |
| 19. | SOUND-ABSORBING SPONGE (SPARK PLUG COVER) | LH2000i-382003 |
| 20. | SOUND-ABSORBING SPONGE (OIL FILLING COVER) | LH2000i-384002 |
| 21. | LIMIT PLATE, RECOIL STARTER HANDLEBAR | LH2000i-383001 |
| 22. | SCREW M3X10 | GB823-1986 |
| 23. | WASHER 4 | GBT97.1-20024 |
| 24. | SPRING WASHER 3 | GBT93-19873 |
