Электрическая схема генератора LH25i
|
Наименование
|
Артикул
|
|
|---|---|---|
| 1. | FLANGE NUT M12X12.5 | GB/T6177.2-2000 M12x1.25 |
| 2. | ROTOR SET | LH2500i-311100A |
| 3. | FLANGE BOLT M5X30 | GB/T5789-1986 M5×30 |
| 4. | 230V/50HZ STATOR SET | LH2500i-311200A |
| 240V/50HZ STATOR SET | LH2500i-311200B | |
| 120V/60HZ STATOR SET | LH2500i-311200C | |
| 5. | PICKUP COIL ASSY | LH2000i-312000 |
| 6. | FLANGE BOLT M5X16 | GB/T5789-1986 M5×16 |
| 7. | IGNITION COIL SET | LH2000i-313000 |
| 8. | FLANGE BOLT M6X18 | GB/T5789-1986 M6×18 |
