Система управления LH2500i
|
Наименование
|
Артикул
|
|
|---|---|---|
| 1. | 230V EU CONTROL PANEL (EN) DUPLEX SOCKET WITH USBSOCKET | LH2500i-361001A |
| 2. | SCREW ST4.2X9.5 | GBT845-F-Hst4.2×9.5 |
| 3. | EUROPE AC SOCKET SET | LH1000i-361700 |
| 4. | SCREW M4X14 | GBT819-2000M4x14 |
| 5. | AC SOCKET GROUNDED CONNECTING LINE | LH2000i-361200 |
| 6. | KNIRLED NUT M5 | LH1000i-360002 |
| 7. | FLANGE NUT M5 | GBT6177.1-2000M5 |
| 8. | AC SOCKET CONNECTING LINE | LH2000i-361300 |
| 9. | DUAL USB SOCKET | LH2000i-367000 |
| 10. | SMART THROTTLE SWITCH SET | LH1000i-361300 |
| 11. | MAIN SWITCH | LH2000i-361400 |
| 12. | CIGARETTE SOCKET | LH2000i-365000 |
| 13. | CHARGING UNIT | LH2000i-366000 |
| 14. | SCREW AND WASHER ST5X15 | GB9074.19-88 ST5x15 |
| 15. | INDICATOR LIGHT TCI SET | LH2000i-361600 |
| 16. | HEXAGON NUT M4 | GBT6170-2000M4 |
| 17. | BOLT M5X16 | GB/T5789-1986 M5×16 |
| 18. | AC SOCKET GROUNDED LINE SET | LH1000i-361400 |
| 19. | CABLE PROTECTIVE HOSE | LH2000i-360001 |
| 20. | CABLE ASSY | LH2000i-363000 |
| 21. | 230V INVERTER SET NON-PARALLEL | LH2500i-362100 |
| 21. | 230V INVERTER SET PARALLEL | LH2500i-362100A |
| 22. | BOLT M6X20 | GBT5787-1986M6x20 |
| 23. | SHOCK ABSORBING RUBBER BLOCK, INVERTER | LH1000i-362001 |
| 24. | NYLON STRIP | LH2000i-360002 |
| 25. | RESET SWITCH | LH1000i-361900 |
| 26. | EUROPE AC SOCKET SET | LH1000i-368000 |
| 27. | CLIP | LH2000i-364200 |
| 28. | PRESS PLATE, STOP SWITHC | LH1000i-364001 |
| 29. | CROSS RECESSED PAN HEAD TAPPING SCREW ST5X20 | GBT845-F-HST4.2X9.5 |
| 30. | CONTROL PANEL DECAL | LH2500i-361004E |
| 31. | GASKET 4X8X0.5 | GB/T848-2002 |
| 32. | SPRING RING 4 | GB/T93-1987 |
| 33. | CHOKE CABLE | LH2000i-383003 |
